Definitive Technology High-Performance Height Speaker Module For Dolby Atmos Or DTS:X - A90

Model #:A90 , UPC #:747192126421

A90 Height Loudspeaker

Seamlessly Integrated Vivid 3-D Sound

If achieving total immersion is the question,the answer is the A90 height speaker module for the BP9020, BP9040, and BP9060 tower loudspeakers. Add a vertical dimension to your home theater and experience every dramatic detail in Dolby Atmos or DTS:X soundtracks.

Clean, Powerful Sound

Balanced Double Surround System Woofers & Aluminum Dome Tweeters

Dolby Atmos & DTS:X

Experience True 3D Sound

Seamless Integration

Connects and Fits Perfectly Atop BP9000 Tower Speakers

Total Immersion

Add More Dimension To Your Sound

The A90 height speaker module easily nestles within the top of your BP9060, BP9040 or BP9020 speakers to deliver completely enveloping Dolby Atmos and DTS:X multidirectional surround sound.

Sloped Design for perfect vertical dispersion

The A90’s internal sloped speaker baffle with anti-resonant construction fires sound upward, reflecting it off the ceiling and back down to your listening area in a tightly controlled dispersion pattern. Sounds appear overhead in sync with on screen action, fully immersing you in the experience.

BDSS™ Woofers & Aluminum Dome Tweeters for powerful, consistent sound

The A90 height speaker module utilizes the same Balanced Double Surround System woofers and Aluminum Dome Tweeters as found in other BP9000 model speakers. Because these technologies are utilized across the entire BP9000 Series, you’ll realize powerful, consistent sound in all dimensions.

Seamless Fit

Fast and Easy Installation

The A90 was designed to fit seamlessly atop your BP9000 tower loudspeakers. A cleverly hidden connector in the BP Tower makes for easy installation, plus there’s no extra cabling required to the height module. There’s no faster or more convenient way to take advantage of Dolby Atmos or DTS:X and add a height dimension to your sound. Note: the BP9080x has a fully integrated height module.

Top Array Driver Complement (1)  1" (2.54 cm) d (Round) Aluminum Dome Tweeter, (1)  4.5" (11.43 cm) d (Round) Midrange
Weight6 lbs (2.72 kg)
Depth13" (33.02 cm)
Width6" (15.24 cm)
Height3.75" (9.53 cm)
Availability US
Total PiecesPair
Drivers Warranty5 years
Original Purchaser OnlyYes
Cabinet Warranty5 years
Electronics Warranty3 years
Total Pieces2
Total Frequency Response86 Hz → 40,000 Hz
Nominal Impedance8 ohms
Max Sensitivity (1 watt @ 1 meter)89.5 dB
