Rich and Immersive
High-Resolution Audio is high-quality sound that exceeds CD standard. High-resolution audio captures and beautifully expresses all the details of your favorite music. Through ultra-high and low frequencies, immerse yourself in a rich and high-quality sonic experience.
HIGH PERFORMANCE PARTS
Special capacitors and inductors have been carefully selected for the digital amplifier’s LC filter, which is essential for achieving highresolution audio. These high-performance parts reduce noise and distortion and ensure excellent sound quality.
DEEP BASS SOUND
By using a down-firing subwoofer and superior technologies, the audio system generates high-quality sound and powerful bass, while still being compact.
ENHANCED SIGNAL TO NOISE RATIO
The feedback value of the current XR Amplifier has been optimized to improve the S/N ratio. As a result, the noise level has been reduced by up to 40%.
SPECIALIZED CIRCUIT DESIGN
The noise reduction system employs a special layout that separates the analog circuit, digital amplifier circuit and power supply circuit. This keeps interference between the circuits to a minimum, decreasing noise and thereby achieving high performance and sound quality.
WIRED REMOTE CONTROL
The wired remote control allows you to adjust the volume of a subwoofer when connected to the head unit.
- Operating Voltage: 14.4V (11 - 16 V allowable)
- Current Consumption: 46 A
- Dimensions (W x H x D): 220 x 35 x 169 mm (8-11/16 x 1-3/8 x 6-5/8)
- Weight: 1.6 kg (3.5 lbs)
- Warranty: 2-Year
|Dimensions (W x H x D)||220 x 35 x 169 mm (8-11/16 x 1-3/8 x 6-5/8)|
|High Pass Filter Frequency||-|
|Low Pass Filter Frequency|
|50 Hz - 200 Hz (variable)||Low-Pass Filter Frequency|
|Signal to Noise Ratio||100 dB|
|Input Impedance||10 kΩ|
|Input Sensitivity||0.2 V - 5.0 V (MIN-MAX)|
|Rated Power Output|
|600 W x 1||(2Ω) (100 Hz, 1.0% THD)|
|400 W x 1||(4Ω) (20 Hz - 200 Hz, 1.0% THD)|
|Max Power Output||-|
|78 dBA||Signal to Noise Ratio (Reference: 1 Watt into 4 ohms)|
|400 W x 1||RMS Watts per channel @ 4 ohms, 1% THD+N|
