Kenwood 4 Inch Coaxial Speaker - KFC-1066S
Model #:KFC-1066S , UPC #:19048222992
$99.00 |
Sound Field Enhancer
To improve sound quality
Enlarged magnet circuit
To realize clear sound
Only 5/16"of mounting height
To fit for wider car selection
Peak Input Power
210W
Rated Input Power
21W Impedance 4 ohms
Woofer Features
4inch PP Cone
Tweeter Features
1inch Balanced Dome Tweeter
Specifications
Sensitivity: 90 dB / W / m
Frequency Response: 45 Hz - 22k Hz
Cutout Diameter: 3-5/8inch
Mounting Depth: 1-11/16inch
Gross Weight: 1.8lbs
Weight of Magnet (Woofer): 0.2lbs
Screw sets | |
---|---|
Screw sets | Tapping Screw , φ4x25*8pcs |
Grille Assy | |
Grille Assy | 2pcs |
Gross Weight | |
Gross Weight | 930 g , 2.0 lbs. |
Weight of Woofer Magnet | |
Weight of Woofer Magnet | 160 g , 5.6 oz. |
without Grille (pc.) | |
without Grille (pc.) | 391 g , 0.9 lbs. |
with Grille (pc.) | |
with Grille (pc.) | 437 g , 1.0 lbs. |
Mounting Depth | |
Mounting Depth | 43 mm , 1-11/16 in. |
Cutout Diameter | |
Cutout Diameter | Φ92.6 , Φ3-5/8 |
Tweeter Height | |
Tweeter Height | 8 mm , 5/16 in. |
Height (w/o_Gr) | |
Height (w/o_Gr) | 104.0 mm , 4-1/8 in. |
Height (w_Gr) | |
Height (w_Gr) | 134.0 mm , 5-1/4 in. |
Width (w/o_Gr) | |
Width (w/o_Gr) | 104.0 mm , 4-1/8 in. |
Width (w_Gr) | |
Width (w_Gr) | 134.0 mm , 5-1/4 in. |
Magnet | |
Magnet | Neodymium |
Size | |
Size | 25mm , 1 in. |
Diaphragm | |
Diaphragm | Balanced Dome , Silver |
Magnet | |
Magnet | Ferrite , φ70xt10 |
Surround | |
Surround | Cloth |
Size | |
Size | 100mm , 4in |
Diaphragm | |
Diaphragm | PP , Silver |
Frequency Response (Hz) | |
Frequency Response (Hz) | 50-22000Hz |
Sensitivity (dB at 1m) | |
Sensitivity (dB at 1m) | 88dB |
RMS Input Power (W) | |
RMS Input Power (W) | 21W |
Peak Input Power (W) | |
Peak Input Power (W) | 220W |
Impedance (Ω) | |
Impedance (Ω) | 4Ω |
